Huawei SUN2000-50KTL-M3 Solar Inverter
Product Description
50kW three-phase string inverter for commercial and industrial solar rooftops, with four MPPT trackers, eight PV inputs and Huawei FusionSolar monitoring.
Huawei official product information
Product selection and support in the Philippines
Review the model-specific specifications and manufacturer documentation before purchase. Check supply phase, PV input limits, system configuration and installation requirements for your project.
Compare solar inverter options · Solar and battery planning guides · Contact JCE POWER in Iloilo or Paranaque
Specifications
Technical Specifications
| Rated AC output | 50,000W |
| Maximum AC apparent power | 55,000VA |
| Maximum / European efficiency | 98.5% / 98.0% |
| Maximum PV input voltage | 1,100V DC |
| MPPT operating range | 200–1,000V DC |
| MPPT trackers / PV inputs | 4 / 8 |
| Maximum current per MPPT / input | 30A / 20A |
| Maximum short-circuit current per MPPT | 40A |
| Grid frequency | 50 / 60Hz |
| Dimensions (W × H × D) | 640 × 530 × 270mm |
| Weight including mounting plate | 49kg |
| Operating temperature | −25°C to +60°C |
Applications
Where It's Used
Commercial & Industrial
50kW three-phase string inverter for commercial and industrial solar rooftops, with four MPPT trackers, eight PV inputs and Huawei FusionSolar monitoring.
