Gospower GPEO-3K6L1-M Solar Inverter

Name: Gospower GPEO-3K6L1-M Solar Inverter
Brand: JCE POWER
SKU: GPEO-3K6L1-M

Model

GPEO-3K6L1-M

Voltage

220/230/240V AC; battery: 24V DC

Power Rating

3kW / 3.6kVA

Warranty

2 years

Recommended max. PV input power

1500W

Max. input voltage(Voc)

145V

MPPT operating voltage range

30V-120V(@36V start up)

Number of MPPT

Max. number of input strings per MPPT

Max. input current per MPPT

25A

Max. short-circuit current per MPPT

27A

Max. input power

4600W

Max. input current

20A

Rated grid voltage

220/230/240Vac (L,N,PE)

Rated grid frequency

50/60Hz

Acceptable range

170-280Vac(For UPS); 90-280Vac (For Home Appliances)

Battery type

LiFePo4/Lead-acid

Battery voltage range

20-30V

Max. charge/discharge current

120A/180A

Rated output power

3000W/3600VA

Rated output current

15.6A

Rated output voltage

220/230/240V(L,N,PE)

Frequency

50/60Hz

Surge power

7200VA 2s

THDv (@ linear load)

<3%

Switching time

10ms typical (For UPS) 20ms typical (For Home Appliances)

Peak efficiency

95%

Max. MPPT efficiency

99.9%

Inner protection

√Output short-circuit protection √Output overvoltage protection

Surge protection

PV: Type lll, AC: Type lll

IP rating

IP21

Operating temperature range

-10°C~ 50°C

Relative humidity range

5%~95%

Max. operating altitude

>2000m derating

Standby self-consumption

<10W

Installation type

Wall-mounted

Cooling mode

Fan cooling

Communication

RS232/RS485

Display

LCD

Inverter dimensions (L*W*H)(mm)

350*290*108

Net weight (kg)

Product Description

Product selection and support in the Philippines

Review the model-specific specifications and manufacturer documentation before purchase. Check supply phase, PV input limits, system configuration and installation requirements for your project.

Compare solar inverter options · Solar and battery planning guides · Contact JCE POWER in Iloilo or Paranaque

Key Features

Single-phase off-grid inverter
Rated active output: 3kW; apparent output: 3.6kVA
Pure sine wave with built-in MPPT
IP21 enclosure
LCD display and RS232/RS485 communication

Send Inquiry WhatsApp Chat

Specifications

Technical Specifications

AC output / Battery

220/230/240V AC, 50/60Hz / 24V DC (20–30V)
