Gospower GPEO-4KL1 Solar Inverter

Name: Gospower GPEO-4KL1 Solar Inverter
Brand: JCE POWER
SKU: GPEO-4KL1

Model

GPEO-4KL1

Voltage

220/230/240V AC; battery: 24V DC

Power Rating

4kW / 4kVA

Warranty

3 years

Recommended max. PV input power

6000W

Max. input voltage(Voc)

500V

MPPT operating voltage range

85V-450V (@85V start up)

Number of MPPT

Max. number of input strings per MPPT

Max. input current per MPPT

15A

Max. short-circuit current per MPPT

18A

Max. input power

6440W

Max. input current

28A

Rated grid voltage

220/230/240Vac

Rated grid frequency

50/60Hz

Acceptable range

170-280Vac(For UPS); 90-280Vac (For Home Appliances)

Battery type

LiFePO4 /Lead-acid

Battery voltage range

20~30Vdc

Max. charge/discharge current

120A/160A

BMS communication mode

RS485

Rated output power

4000W/4000VA

Rated output current

18.2A

Rated output voltage/frequency

220/230/240Vac 50/60Hz

Surge power

8000VA 5S

THDv (@ linear load)

<3%

Switching time

10ms typical (For UPS) 20ms typical (For Home Appliances)

Peak efficiency

95%

Max. MPPT efficiency

99.9%

Inner protection

√Output short-circuit protection √Output overvoltage protection

Surge protection

PV: Type lll, AC: Type lll

IP rating

IP54

Operating temperature range

-10°C~ 55°C

Relative humidity range

5%~95%

Max. operating altitude

>2000m derating

Standby self-consumption

<10W

Installation type

Wall-mounted

Cooling mode

Fan cooling

Communication

RS232/RS485/Dry contact/WI-FI

Display

LCD

Inverter dimensions (L*W*H)(mm)

445*347*120

Net weight(kg)

9.2

Product Description

Product selection and support in the Philippines

Review the model-specific specifications and manufacturer documentation before purchase. Check supply phase, PV input limits, system configuration and installation requirements for your project.

Compare solar inverter options · Solar and battery planning guides · Contact JCE POWER in Iloilo or Paranaque

Key Features

4kW single-phase off-grid inverter
Pure sine wave output
Built-in MPPT with 85–450V operating range
IP54 enclosure
Built-in BMS communication

Send Inquiry WhatsApp Chat

Specifications

Technical Specifications

AC output / Battery

220/230/240V AC, 50/60Hz / 24V DC (20–30V)
